| Line | BASS |
| Reference | 01 |
| Operation Class | BASS 30K |
| Number of Channels | Classe D |
| Max Output Power | @ 14,4 VDC – 1 OHM: 30000 W RMS @ 14,4 VDC – 2 OHMS: 17010 W RMS |
| Input Sensitivity | 400mV |
| Signal Noise/Ratio | >90dB |
| Frequency Response | (-3dB) 8Hz a 250Hz |
| Crossover High Pass (HPF) | Variable, 8 a 30Hz (-12dB/8ª) |
| Crossover Low Pass (LPF) | Variable, 60 a 250Hz (-12dB/8ª) |
| Bass Boost | Parametric, (35 a 60Hz) 0 a +12dB |
| Efficiency | 90% |
| Input Impedance | 22K Ohms |
| Protection System | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| Minimum Supply Voltage | 9VDC |
| Maximum Supply Voltage | 17VDC |
| Idle Consumption | 400mA |
| Musical Maximum Consumption | 1156A |
| Sinusoidal Signal Maximum Consumption | 2312A |
| Dimensions (WxHxD) | 238 x 71 x 1044 mm |
| Weight | 19,20Kg |
